Chevrolet Caprice IV (1990-1996) rear compartment courtesy lamp automatic level control sensor Wiring diagram

AUXILIARY DOME LAMP BASE OF LH "A" PILLAR BEHIND KICKPAD BATTERY BLK WIRE BLOWER MOTOR CONTROL MODULE BODY 1 FUSE #10 BODY 2 FUSE #11 BUICK (CHEVROLET WAGON, ALL BUICK) SEDAN BUICK SEDAN WAGON CHEVROLET CLUST CHI FUSE #33 PASSKEY FUSE #34 CONVENIENCE CENTER CTSY PWR LOCK FUSE 35 DOME LAMP GENERATOR HAZARD LAMP FLASHER HEATER-A/C CONTROL HIGH BLOWER RELAY HVAC MOD FUSE #40 I/P CLUSTER I/P COMPARTMENT LAMP I/P COMPARTMENT LAMP SWITCH I/P FUSE BLOCK INT LPS FUSE #27 LEFT FRONT DOOR LOCK SWITCH LEFT REAR COURTESY LAMP COURTESY LAMP RELAY CONVENIENCE CENTER LEFT ROOF RAIL COURTESY AND READING LAMP LH FRONT DOOR COURTESY LAMP RH FRONT DOOR COURTESY LAMP LH REAR DOOR COURTESY LAMP LIFTGATE WIPER LATCH SWITCH REMOTE CONTROL DOOR LOCK RECEIVER MERCURY SWITCH NCA WIRE ORG/ WIRE PRIMARY COOLING FAN RELAY PRMRY CLG FAN FUSE #12 RADIO RADIO POWER ANTENNA RELAY REAR COMPARTMENT COURTESY LAMP AUTOMATIC LEVEL CONTROL SENSOR REAR COMPARTMENT LID RELEASE RELAY REAR WINDOW DEFOGGER RELAY REAR WINDOW DEFOGGER SWITCH REAR WINDOW WIPER MOTOR REAR COMPARTMENT LID PULL-DOWN ACTUATOR RED WIRE RH I/P DOOR LAMP LH I/P DOOR LAMP RIGHT FRONT DOOR LOCK SWITCH RIGHT REAR COURTESY LAMP RIGHT ROOF RAIL COURTESY AND READING LAMP INSIDE REARVIEW MIRROR RIGHT SUNSHADE ILLUMINATED MIRROR RR DEFG CIRCUIT BREAKER #4 RR REL FUSE #29 CIG FUSE #28 SCNDRY CLG FAN FUSE #13 SECONDARY COOLING FAN RELAY UNDERHOOD ELECTRICAL CENTER SEDAN SEO STARTER SOLENOID STOP LAMP SWITCH STOP/ HZD FUSE #37 THEFT DETERRENT MODULE TO FUSIBLE LINKS A, B TO I/P FUSE BLOCK TO IGNITION SWITCH TRK PDWN -OR- RR WIPER FUSE #36 UNDERHOOD ELECTRICAL CENTER W/KEYLESS WAGON ENTRY WAGON WARNING ALARM
