Chevrolet Caprice IV (1990-1996) lts on warning input ignition delay on/off output #2 output #1 Wiring diagram
This page shows the only wiring diagram for the component.lts on warning input ignition delay on/off output #2 output #1, which is found in the car Chevrolet Caprice IV (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lts on warning input ignition delay on/off output #2 output #1 (1 of 1)
AMBIENT LT SENSOR INPUT
BLK WIRE
BLK/WHT 1491 WIRE
BLK/WHT WIRE
BRN WIRE
CONN 1
CONN 2
DK GRN/WHT WIRE
EXT LPS FUSE
EXTERIOR LTS
FUS LINK A (UNDERHOOD ELECTRICAL CENTER)
GROUND
HEAD
HEADLT AUTO CONTROL MODULE (ABOVE BASE OF STEERING COLUMN)
HEADLT AUTO CTRL AMBIENT LT SENSOR
HEADLT DIMMER
HEADLT SW
HI BEAM GROUND B+
HI-BEAM IND
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK CHIME FUSE
INSTRUMENT CLUSTER
INTERIOR, EXTERIOR LTS
INTERNAL HEAD RELAY
INTERNAL PARK RELAY
LEFT DUAL BEAM HEADLT
LT GRN LT GRN WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LTS ON INPUT
LTS ON WARNING INPUT IGNITION DELAY ON/OFF OUTPUT #2 OUTPUT #1
MAX
MIN PPL
NOT USED
OFF
ORG/ WIRE
PARK
PNK PPL WIRE
PNK WIRE
RED WIRE
RIGHT DUAL BEAM HEADLT
TAN WIRE
TWILIGHT SENTINEL SW
WARNING ALARM (CONVENIENCE CENTER)
YEL WIRE
YEL/BLK WIRE
