Chevrolet Caprice IV (1990-1996) liftgate wiper latch switch Wiring diagrams
This page contains all the electrical diagrams for the component. liftgate wiper latch switch, in which he is found in the car Chevrolet Caprice IV (1990-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram liftgate wiper latch switch (1 of 2)
ACCESSORY SWITCH PANEL (LEFT I/P)
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER
DK BLU WIRE
END GATE RELEASE RELAY
HOT AT ALL TIMES
I/P FUSE BLOCK
LIFTGATE WIPER LATCH SWITCH
ORG/ WIRE
ORG/BLK WIRE
PARK/ NEUTRAL POSITION SWITCH (ON STEERING COLUMN)
REAR GLASS RELEASE ACTUATOR
REAR GLASS RELEASE SWITCH
REAR REL FUSE
TAILGATE LOCK SENSE SWITCH (CLOSED IN UNLOCK)
UNLOCK
WHT WIRE
Go to component -> Rear glass release circuit, without power locks -> LIFTGATE WIPER LATCH SWITCH
Wiring diagram liftgate wiper latch switch (2 of 2)
ACCESSORY SWITCH PANEL
BLK WIRE
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
LIFTGATE WIPER LATCH SWITCH
OFF
OFF ON ON
ORG/ WIRE
PARK
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER/ WASHER AND MULTI- FUNCTION SWITCH
REAR WIPER WASHER MOTOR (ON WASHER RESERVOIR)
RR WIPER FUSE #8
RUN WIRE
SOLID STATE
TRK P/DOWN FUSE #36
WASH
WIPE
YEL WIRE
Go to component -> Rear washer/wiper circuit -> LIFTGATE WIPER LATCH SWITCH
