Chevrolet Caprice IV (1990-1996) (left front of engine compartment, on front Wiring diagram
This page shows the only wiring diagram for the component.(left front of engine compartment, on front, which is found in the car Chevrolet Caprice IV (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (left front of engine compartment, on front (1 of 1)
4000 PULSES/MILE
BATTERY
BLK/WHT WIRE
BRN WIRE
BUICK ONLY
CHEVY BUICK
CRUISE CONTROL IND
CRUISE CONTROL MODULE (FASTENED TO LEFT
CRUISE CONTROL RELEASE SW (ON BRAKE PEDAL SUPPORT)
CRUISE FUSE
CRUISE STATUS VSS INPUT
CRUISE SW
DISTANCE TRAVELED INPUT
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT 817 WIRE
DK GRN/WHT WIRE
F/P FUSE TRANS FUSE
FRONT WHEEL HOUSE)
GROUND
GRY WIRE
HAZARD LAMP FLASHER
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR
I/P INDIC FUSE
IGNITION SIG
INST PANEL FUSE BLOCK
INSTRUMENT CLUSTER
MULTIFUNCTION LEVER
NCA WIRE
OF LEFT CYLINDER HEAD)
OFF
OFF ON
ORG/ WIRE
PNK PNK PPL WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PPL
SET R/A SW
STOP/HZD FUSE
STOPLAMP SW (ON BRAKE PEDAL SUPPORT)
VEHICLE SPEED INPUT
VEHICLE SPEED SENSOR
VSS INPUT/LO VSS INPUT/HI
WARNING ALARM MODULE
WHT WIRE
YEL WIRE
