Chevrolet Caprice IV (1990-1996) fasten belts pass key fault indicator indicator Wiring diagram

A/C DRL FUSE ABS INDICATOR AIR BAG INDICATOR BLK WIRE BLK/WHT WIRE BRAKE INDICATOR BRAKE PRESSURE MODULATOR VALVE BRN WIRE BRN/WHT WIRE BULB TEST LOCK OFF CHANGE OIL IND. CTRL LOW OIL LVL IND. CTRL OIL LVL INPUT CHECK GAUGE CLUS CHI FUSE CONVENIENCE CENTER CONVENIENCE CENTER (LEFT KICK PANEL) (LEFT I/P, LEFT OF STEERING COLUMN) COOLANT TEMP DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DOME COURTESY LAMP RELAY DOOR OPEN INDICATOR ELECTRONIC BRAKE CONTROL MODULE ABS IND. CTRL ENG/ MET STEP DIM ENGINE COOLANT TEMP. GAUGE ENGINE COOLANT TEMPERATURE SENDER ENGINE OIL LEVEL SWITCH FASTEN BELTS PASS KEY FAULT INDICATOR INDICATOR FUEL GAUGE FUEL LEVEL FUSE BLOCK- I/P GATE AJAR GEN OUT (MOUNTED IN WASHER SOLVENT RESERVOIR) GENERATOR GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HI BEAM HOT AT ALL TIMES HOT AT ALL TIMES FUSE BLOCK: I/P CTSY PWR LOCK FUSE HOT IN RUN HOT IN RUN OR START I/P INDC FUSE IGN IGN 3 IGNITION SWITCH ILLUMIN- ATION (2 BULBS) ILLUMIN- ATION (3 BULBS) IND. CTRL (LEFT I/P, LEFT OF BRAKE PEDAL BRACKET) (LEFT KICK PANEL) INDIC- ATOR INDICATOR (WAGON ONLY) INDICATOR CONTOLS INSTRUMENT CLUSTER INSTRUMENT CLUSTER ENGLISH/ METRIC SWITCH LEFT TURN LH FRONT DOOR JAMB SWITCH LH REAR DOOR JAMB SWITCH LOW COOLANT INDICATOR LOW ENGINE COOLANT INDICATOR PROBE LOW FUEL LOW OIL LEVEL INDICATOR CHANGE OIL INDICATOR LOW WASHER FLUID LT BLU WIRE LT GRN WIRE MALFUNCTION INDICATOR OIL PRESS GAUGE OIL PRESSURE RESISTOR OIL PRESSURE SENDER ORG/ WIRE PARK BRAKE IN (RIGHT KICK PANEL) PPL PARK BRAKE SWITCH PNK WIRE POWERTRAIN CONTROL MODULE POWERTRAIN CONTROL MODULE MIL IND. CTRL (FORWARD OF LEFT FRONT WHEELHOUSE) PPL PPL IGNITION SWITCH BRAKE PRESSURE SWITCH PPL PPL PPL PPL DAYTIME RUNNING LIGHTS MODULE BRAKE IND. CTRL PRESS. RELAY CONTROL WARNING ALARM DOOR OPEN INPUT RH REAR DOOR JAMB SWITCH RH FRONT DOOR JAMB SWITCH RIGHT TURN RUN WIRE SENDER (MOUNTED IN FUEL TANK) SEO NON-SEO SIR IND. CTRL SOLID STATE SOLVENT LEVEL GND GEN TAILGATE AJAR SWITCH TAN WIRE TAN/WHT WIRE THEFT DETERRENT MODULE PASS KEY FAULT TRIP RESET VEHICLE SPEED INPUT VEHICLE SPEED OUPUT VF SPEEDOMETER DISLAY VOLT GAUGE W/ DRL W/O DRL WASHER SOLVENT LEVEL SWITCH WHT WIRE WIND- SHIELD YEL WIRE
