Chevrolet Caprice IV (1990-1996) auto headlamp or drl control module Wiring diagram
This page shows the only wiring diagram for the component.auto headlamp or drl control module, which is found in the car Chevrolet Caprice IV (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto headlamp or drl control module (1 of 1)
ASHTRAY
AUTO HEADLAMP OR DRL CONTROL MODULE
BASE
BLK WIRE
BRN WIRE
CONVENIENCE CENTER (LEFT SIDE OF I/P)
COURTESY LAMPS CIRCUIT
COURTESY SWITCH
DIMMING SWITCH
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HEAD OFF PARK
HEADLIGHT SWITCH
HEATER AND A/C CONTROL
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF I/P)
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER ENGLISH/ METRIC SWITCH
INSTRUMENT PANEL DIMMER MODULE (LOWER INSTRUMENT PANEL REINFORCEMENT)
INSTRUMENT PANEL LAMP DIMMER
INT DIM FUSE 42
LIGHTS ON SIGNAL
RADIO ANALOG DIM INPUT
REAR WINDOW WIPER/ WASHER, MULTI- FUNCTION SWITCH (WAGON)
WARNING ALARM
WHT WIRE
WITH DRL OR TWILIGHT SENTINEL
YEL WIRE
Go to component -> Instrument illumination circuit -> AUTO HEADLAMP OR DRL CONTROL MODULE
