Chevrolet Caprice Impala SS (1995-1996) Charging circuit

"VOLTS" (EXCEPT CAPRICE) "CHECK GAGE" (CAPRICE) INDICATOR BATTERY BLK WIRE BRN WIRE GENERATOR HOT IN RUN HOT IN RUN OR START I/P FUSE BLOCK I/P INDC FUSE #11 INSTRUMENT CLUSTER PNK (BUICK) (CAPRICE) WIRE PNK WIRE POWER DISTRIBUTION SYSTEM SEC FAN FUSE #8 UNDERHOOD ELECTRICAL CENTER
