Chevrolet Caprice Impala SS (1995-1996) rear window wiper/ washer and multi- function switch Wiring diagram
This page shows the only wiring diagram for the component.rear window wiper/ washer and multi- function switch, which is found in the car Chevrolet Caprice Impala SS (1995-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window wiper/ washer and multi- function switch (1 of 1)
1995 VFTC
ACCESSORY SWITCH PANEL
BLK WIRE
ENDGATE WINDOW RELEASE SWITCH (CENTER OF TAILGATE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
I/P FUSE BLOCK
OFF
OFF ON
ORG/ WIRE
PARK
REAR WASHER MOTOR (ON WASHER RESERVOIR)
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER/ WASHER AND MULTI- FUNCTION SWITCH
RR WIPER FUSE #8
RUN WIRE
SOLID STATE
TRK P DOWN FUSE 36
WASH
WIPE
YEL WIRE
