Chevrolet Caprice Impala SS (1995-1996) photocell input photocell input delay ignition ground Wiring diagram

1995 VFTC AUDIBLE WARNINGS B+ OUTPUT #2 OUTPUT #1 BLK WIRE BLK/WHT WIRE BRN WIRE BUICK, IMPALA CHI BODY FUSE #13 CONVENIENCE CENTER (LEFT SIDE OF I/P, LEFT OF STEERING COLUMN) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE EXT LPS FUSE 31 FUSIBLE LINK A GRY WIRE HEAD LAMP AUTOMATIC CONTROL MODULE (RIGHT "A" PILLAR, BEHIND KICKPAD) HEADLAMP DIMMER SWITCH HEADLAMP SWITCH/ HEADLAMP, I/P DIMMER SWITCH HI BEAM HI BEAM INDICATOR HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK IMPALA INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (BUICK ONLY) INTERNAL HEAD RELAY INTERNAL PARK RELAY LEFT HEADLAMP LPS ON INPUT LPS ON WARNING INPUT LT GRN WIRE LT GRN/BLK WIRE MAX MIN OFF PARK HEAD OPENS AT EXTREME DIM POSITION ORG/ WIRE PHOTOCELL INPUT PHOTOCELL INPUT DELAY IGNITION GROUND PNK WIRE PPL PPL PNK WIRE RED WIRE RIGHT HEADLAMP TAN WIRE TWILIGHT SENTINEL SWITCH VF SPEED- OMETER DISPLAY HI BEAM INDICATOR WHT WIRE YEL WIRE YEL/BLK WIRE
