Chevrolet Caprice Impala SS (1995-1996) endgate window release actuator Wiring diagrams
This page contains all the electrical diagrams for the component. endgate window release actuator, in which he is found in the car Chevrolet Caprice Impala SS (1995-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
endgate window release actuator wiring diagram (1 of 3)
1995 VFTC
ACT CNTRL
B+ SW SIG
BLK WIRE
BLK/WHT WIRE
CHI BODY FUSE
CTSY PWR LK FUSE
DK BLU WIRE
DOOR LOCK RELAY (UNDER LEFT REAR SEAT)
ENDGATE WINDOW RELEASE ACTUATOR
EXTERIOR LIGHTS SYSTEM (TURN SIGNAL SWITCH)
GROUND
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
I/P FUSE BLOCK (LEFT SIDE OF I/P)
KEYLESS ENTRY PROGRAMMING CONNECTOR (LEFT SIDE OF REAR COMPT)
LEFT FRONT DOOR LOCK ACTUATOR
LEFT POWER DOOR LOCK SWITCH
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LOCK RELAY
LT BLU WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION SWITCH
PNK PNK IGN IGN LK SIG UNLK SIG BRAKE SIG WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) PARK/ NEUTRAL SIGNAL
PROG IN
PWR LK FUSE
REAR COMPARTMENT LID LOCK RELEASE ACTUATOR
REAR COMPARTMENT LID RELEASE RELAY (IN CONVENIENCE CENTER)
REAR COMPARTMENT LID RELEASE SOLENOID
REMOTE CONTROL DOOR LOCK RECEIVER (FRONT OF REAR COMPT, ATTACHED TO REAR SHELF)
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT POWER DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
RR REL FUSE
SEDAN
STOP/HZD FUSE
STOPLAMP SWITCH (ATTACHED TO BRAKE PEDAL BRACKET)
TAN WIRE
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNLOCK
UNLOCK RELAY
WAGON
WAGON SEDAN
WHT WIRE
Go to component -> Keyless entry circuit -> ENDGATE WINDOW RELEASE ACTUATOR
endgate window release actuator wiring diagram (2 of 3)
1995 VFTC
ACCESSORY SWITCH PANEL (LEFT I/P)
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER
DK BLU WIRE
ENDGATE LOCK SENSE SWITCH (CLOSED IN UNLOCK)
ENDGATE UPPER LATCH SWITCH
ENDGATE WINDOW RELEASE ACTUATOR
ENDGATE WINDOW RELEASE RELAY
ENDGATE WINDOW RELEASE SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK
ORG/ WIRE
ORG/BLK WIRE
PARK/ NEUTRAL POSITION SWITCH (ON STEERING COLUMN)
RR REL FUSE 29
UNLOCK
Go to component -> Rear glass release circuit, without keyless entry -> ENDGATE WINDOW RELEASE ACTUATOR
endgate window release actuator wiring diagram (3 of 3)
1995 VFTC
ACCESSORY SWITCH PANEL
BLK WIRE
BLK/WHT WIRE
CONVENIENCE CENTER (BEHIND LEFT SIDE OF I/P)
DK BLU WIRE
ENDGATE LOCK SWITCH (CLOSED IN UN- LOCK POSITION)
ENDGATE UPPER LATCH SWITCH (NORMALLY OPEN)
ENDGATE WINDOW RELEASE ACTUATOR
ENDGATE WINDOW RELEASE RELAY
ENDGATE WINDOW RELEASE SWITCH
ENGINE CONTROLS SYSTEM
HOT AT ALL TIMES
I/P FUSE BLOCK (MOUNTED TO LEFT SIDE OF I/P)
ORG/ WIRE
ORG/BLK WIRE
PARK/ NEUTRAL POSITION SWITCH (ATTACHED TO AUTOMATIC TRANSMISSION)
REAR REL FUSE 29
Go to component -> Tailgate release circuit -> ENDGATE WINDOW RELEASE ACTUATOR
