Chevrolet Caprice Impala SS (1995-1996) 29 7 uart data data clss 2 ppl Wiring diagram
This page shows the only wiring diagram for the component.29 7 uart data data clss 2 ppl, which is found in the car Chevrolet Caprice Impala SS (1995-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 29 7 uart data data clss 2 ppl (1 of 1)
29 7 UART DATA DATA CLSS 2 PPL
BLK WIRE
BLK/WHT WIRE
BUICK ONLY
CIG/DLC FUSE
DATA LINK CONNECTOR (BELOW LEFT SIDE OF I/P, RIGHT OF STEERING COLUMN)
ELECTRONIC POWER STEERING SYSTEM
HEATER AND A/C CONTROL (BUICK W/ AUTO ELECTRONIC HVAC ONLY)
HOT AT ALL TIMES
I/P FUSE BLOCK
ORG/ WIRE
POWER STEERING CONTROL MODULE (BUICK ONLY) (BEHIND LEFT I/P, NEAR FUSE BLOCK)
POWER STEERING PUMP ACTUATOR
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
PPL
TAN WIRE
UART DATA
WHT WIRE
Go to component -> Computer data lines -> 29 7 UART DATA DATA CLSS 2 PPL
