Car Wiring Diagrams for Electrochromic mirror circuit, w/ full video display for Chevrolet Camaro VI facelift (2018-2024)

BK COAX BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE COAX DISPLAY DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER OUTSIDE REAR- VIEW MIRROR GRN/WHT WIRE HOT W/ IGNITION MAIN RELAY ENERGIZED INSIDE REAR VIEW MIRROR LOGIC MIRROR DIMMING NCA WIRE REAR VIEW CAMERA UNDERHOOD FUSE BLOCK VIO/WHT WIRE YEL/WHT WIRE
