Chevrolet Camaro VI facelift (2018-2024) rf susp pos sens sig Wiring diagram

BATTERY POSITIVE VOLT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY ESC IND ESC OFF IND GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRY/GRN WIRE HI SPD GMLAN SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA (-) (2) HI SPD GMLAN SERIAL DATA (-) (2) SERIAL DATA COMM ENABLE HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT FRONT SHOCK ABSORBER ACTUATOR LEFT FRONT SUSPENSION POSITION SENSOR LEFT REAR SHOCK ABSORBER ACTUATOR LEFT REAR SUSPENSION POSITION SENSOR LF SHOCK ABS ACT DECREASE DAMP CTRL LF SHOCK ABS ACT INCREASE DAMP CTRL LF SUSP POS SENS LOW REF LF SUSP POS SENS SIG LF SUSP POS SENS VOLT REF LOGIC LOW SPD GMLAN SERIAL DATA 2 LR ABS ACT DECREASE DAMP CTRL LR ABS ACT INCREASE DAMP CTRL LR STRUT POS SENS SIG LR SUSP POS SENS LOW REF LR SUSP POS SENS VOLT REF NCA WIRE REAR BODY FUSE BLOCK RED/BLU WIRE RF SHOCK ABS ACT DECREASE DAMP CTRL RF SHOCK ABS ACT INCREASE DAMP CTRL RF SUSP POS SENS LOW REF RF SUSP POS SENS SIG RF SUSP POS SENS VOLT REF RIGHT FRONT SHOCK ABSORBER ACTUATOR RIGHT FRONT SUSPENSION POSITION SENSOR RIGHT REAR SHOCK ABSORBER ACTUATOR RIGHT REAR SUSPENSION POSITION SENSOR RR ABS ACT DECREASE DAMP CTRL RR ABS ACT INCREASE DAMP CTRL RR SUSP POS SENS LOW REF RR SUSP POS SENS SIG RR SUSP POS SENS VOLT REF SUSPENSION CONTROL MODULE VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/GRY WIRE YEL WIRE YEL/RED WIRE YEL/WHT WIRE
