Chevrolet Camaro VI facelift (2018-2024) radio keypad button sig radio volume up switch sig radio volume down switch sig Wiring diagram

AUXILIARY AUDIO COMMON SIGNAL BACKLIGHT LOW REF BACKUP LAMP CTRL LOW SPEED GMLAN SERIAL DATA 2 BATTERY POSITIVE VOLTAGE BK COAX BK COAX AM/FM BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/WHT WIRE CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX COAX OG FRONT VISION CAMERA 1 COAXIAL VIDEO SIG COAX TN COMPUTER DATA LINES SYSTEM GMLAN SERIAL DATA 2 GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES INTERRUPT REQUEST SIG KEYPAD DIMMING CTRL KEYPAD VOLTAGE REF LEFT FRONT DOOR SPEAKER LEFT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE LEFT FRONT TWEETER SPEAKER LEFT REAR TRIM PANEL SPEAKER LF SPEAKER (-) CTRL 1 LF SPEAKER SIG (-) 1 LR SPEAKER (+) CTRL LR SPEAKER SIG (-) LVDS LVDS GY INFOTAINMENT DISPLAY SIG MICROPHONE 1 FEEDBACK SIG MICROPHONE 1 SIG MICROPHONE 2 FEEDBACK SIG MICROPHONE 2 SIG NCA WIRE RADIO RADIO KEYPAD BUTTON SIG RADIO VOLUME UP SWITCH SIG RADIO VOLUME DOWN SWITCH SIG REAR BODY FUSE BLOCK REAR VIEW CAMERA RED/BRN WIRE RED/VIO WIRE RED/YEL WIRE RF SPEAKER (-) CTRL 1 RF SPEAKER SIG (-) 1 RIGHT FRONT DOOR SPEAKER RIGHT FRONT RADIO VOLUME COMPENSATOR INTERIOR NOISE MICROPHONE RIGHT FRONT TWEETER SPEAKER RIGHT REAR TRIM PANEL SPEAKER RR SPEAKER (+) CTRL RR SPEAKER SIG (-) SIGNAL GROUND TN COAX XM USB USB USB VIO WIRE VIO/BLU WIRE VIO/WHT WIRE VOICE RECOGNITION CTRL VOICE RECOGNITION AUDIO SIG W/ ACTIVE NOISE W/ VEHICLE PERFORMANCE DATA RECORDER W/O ACTIVE NOISE W/O VEHICLE PERFORMANCE DATA RECORDER WHT WIRE YEL WIRE YEL/BLK WIRE
