Car Wiring Diagrams for Memory mirrors circuit for Chevrolet Camaro VI (2015-2018)

BATT POSITIVE VOLT BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DRIVER OUTSIDE REAR VIEW MIRROR GLASS DRIVER OUTSIDE REAR VIEW MIRROR MOTOR DRIVER OUTSIDE REAR- VIEW MIRROR DRIVER SIDE OBJECT DETECTION INDICATOR DRIVER WINDOW SWITCH DRV MIR MTR COMMON CTRL DRV MIR MTR RH (+) LH (-) CTRL DRV MIR MTR UP (+) DOWN (-) CTRL DRV MIR POSITION SENS 5 VOLT REF DRV MIR POSITION SENS LH (-) RH (+) SIG DRV MIR POSITION SENS LO REF DRV MIR POSITION SENS UP (+) DOWN (-) SIG GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT TURN SIGNAL REPEATER LAMP LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 8 MIR WNDW MDL FUSE MIRROR DIMMING MIRRORS SYSTEM NAVIGATION SYSTEM NCA WIRE PASS WDW FUSE REAR BODY FUSE BLOCK RED/BLU WIRE RED/VIO WIRE RED/WHT WIRE UNDERHOOD FUSE BLOCK VIO WIRE VIO/BLU WIRE VIO/RED WIRE WHT WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/WHT WIRE

BATT POSITIVE VOLT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DRIVER SEAT MEMORY CONTROL MODULE (UNDER DRIVER SEAT CUSHION) DRIVER SEAT MEMORY SWITCH EXIT SWITCH GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE ILL LOCAL INTERCONNECT NETWORK SERIAL DATA BUS 8 LOGIC LOW SPD GMLAN SERIAL DATA MEM SEAT SW SET SIG MEM SEAT SW SIG (1) MEM SW LO REF MEMORY 1 SWITCH MEMORY 2 SWITCH NAVIGATION SYSTEM NCA WIRE PASS MIR MTR COMMON CTRL PASS MIR MTR RH (+) LH (-) CTRL PASS MIR MTR UP (+) DOWN (-) CTRL PASS MIR POSITION SENS 5 VOLT REF PASS MIR POSITION SENS LH (-) RH (+) SIG PASS MIR POSITION SENS LO REF PASS MIR POSITION SENS UP (+) DOWN (-) SIG PASSENGER OUTSIDE REAR VIEW MIRROR PASSENGER OUTSIDE REAR VIEW MIRROR GLASS PASSENGER OUTSIDE REAR VIEW MIRROR MOTOR PASSENGER SIDE OBJECT DETECTION INDICATOR PASSENGER WINDOW SWITCH RED/BLU WIRE RED/WHT WIRE RIGHT TURN SIGNAL REPEATER LAMP SET SWITCH VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/RED WIRE YEL/VIO WIRE
