Chevrolet Camaro VI (2015-2018) pedestrian protection safing sensor module sig Wiring diagram
This page shows the only wiring diagram for the component.pedestrian protection safing sensor module sig, which is found in the car Chevrolet Camaro VI (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pedestrian protection safing sensor module sig (1 of 1)
AIR BAG MDL/AOS FUSE
BATT POS VOLT
BLK/ORG WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
HI SPD GMLAN SERIAL DATA (-) (1)
HI SPD GMLAN SERIAL DATA (-) (2)
HOT AT ALL TIMES
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
LEFT HOOD ACTUATOR HI CTRL
LEFT HOOD ACTUATOR LOW CTRL
LEFT HOOD HINGE ACTUATOR
ORG/ WIRE
ORG/VIO WIRE
PEDESTRIAN PROTECTION IMPACT SENSING MODULE LOW REF
PEDESTRIAN PROTECTION IMPACT SENSING MODULE SIG
PEDESTRIAN PROTECTION SAFING SENSOR MODULE LOW REF
PEDESTRIAN PROTECTION SAFING SENSOR MODULE SIG
POWER DISTRIBUTION SYSTEM
RED/GRN WIRE
RIGHT HOOD ACTUATOR HI CTRL
RIGHT HOOD ACTUATOR LOW CTRL
RIGHT HOOD HINGE ACTUATOR
SHORTING BAR
SIG GND
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK
UPPER BEAM FRONT PEDESTRIAN IMPACT DETECTION SENSOR
VIO/RED WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Active bodyworks circuit -> PEDESTRIAN PROTECTION SAFING SENSOR MODULE SIG
