Chevrolet Camaro VI (2015-2018) ltd slip diff sol hi side ctrl Wiring diagram
This page shows the only wiring diagram for the component.ltd slip diff sol hi side ctrl, which is found in the car Chevrolet Camaro VI (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ltd slip diff sol hi side ctrl (1 of 1)
BATTERY POSITIVE VOLT
BLK WIRE
BLU WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL CLUTCH PUMP (ON REAR DIFFERENTIAL CASE)
DISPLAY
DRAIN WIRE
ELSD FUSE
GRN WIRE
GROUND
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HI SPD GMLAN SERIAL DATA (-) (2)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LOGIC
LOW REF
LTD SLIP DIFF SOL HI SIDE CTRL
LTD SLIP DIFF SOL LO SIDE CTRL
MOST SERIAL DATA (+)
REAR AXLE TEMP SIG
REAR BODY FUSE BLOCK
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR DIFFERENTIAL CLUTCH SOLENOID VALVE
REAR DIFFERENTIAL OIL PRESSURE/ TEMPERATURE SENSOR
REAR DIFFERENTIAL OIL TEMPERATURE SENSOR
RED WIRE
RED/VIO WIRE
RED/WHT WIRE
RR DIFF OIL PRESS SENS
RR DRIVE CNTRL MDL FUSE
RR DRIVE MTR HI SIDE CTRL
RR DRIVE MTR LOW SIDE CTRL
SERIAL DATA COMM ENABLE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Rear differential lock circuit -> LTD SLIP DIFF SOL HI SIDE CTRL
