Chevrolet Camaro VI (2015-2018) folding top stowage compartment lid open position sensor Wiring diagram
This page shows the only wiring diagram for the component.folding top stowage compartment lid open position sensor, which is found in the car Chevrolet Camaro VI (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram folding top stowage compartment lid open position sensor (1 of 1)
BATTERY FUSE BLOCK
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FOLDING TOP LUGGAGE BARRIER SENSOR
FOLDING TOP PUMP MOTOR
FOLDING TOP PUMP MOTOR RELAY 1
FOLDING TOP PUMP MOTOR RELAY 2
FOLDING TOP PUMP/ MOTOR ASSEMBLY
FOLDING TOP SOLENOID VALVE 1
FOLDING TOP SOLENOID VALVE 2
FOLDING TOP SOLENOID VALVE 3
FOLDING TOP STOWAGE COMPARTMENT LID OPEN POSITION SENSOR
FUSE 4
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
IN LUGGAGE COMPT)
LEFT FOLDING TOP HEADER LATCHED POSITION SENSOR
LEFT FOLDING TOP STOWAGE COMPARTMENT LID CLOSED POSITION SENSOR
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BRN WIRE
RIGHT FOLDING TOP HEADER LATCHED POSITION SENSOR
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Electric folding sunroof circuit (2 of 2) -> FOLDING TOP STOWAGE COMPARTMENT LID OPEN POSITION SENSOR
