Pass-key circuit for Chevrolet Camaro V facelift (2013-2015)
Pass-key circuit
3 2 1 IMMOBILIZER POWER LINEAR INTERCONNECT
BATT POSITIVE VOLT
BCM 8 FUSE
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
HOOD AJAR SW SIG
HOOD AJAR SWITCH
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
IMMOBILIZER CONTROL MODULE (UPPER STEERING COLUMN)
IMMOBILIZER POWER LINEAR INTERCONNECT NETWORK 11 IMMOBILIZER GND
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LINEAR INTERCONNECT
LO SPD SERIAL DATA
LOGIC
LOW REFERENCE
LT BLU WIRE
NCA WIRE
NETWORK 11
NETWORK 11 IMMOBILIZER GND
PNK/BLK WIRE
RED/WHT WIRE
SECURITY INDICATOR
SERIAL DATA
