Chevrolet Camaro V facelift (2013-2015) suspension control subwoofer module speaker Wiring diagram
This page shows the only wiring diagram for the component.suspension control subwoofer module speaker, which is found in the car Chevrolet Camaro V facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram suspension control subwoofer module speaker (1 of 1)
3.6L
3.6L 6.2L
6.2L, 7.0L
6.2L, 7.0L 3.6L
70 18 3.6L 6.2L
A/T
AMP FUSE
AMP FUSE RTD FUSE
AUDIO AMPLIFIER
AUTOMATIC TRANSMISSION ASSEMBLY
BLK WIRE
BODY CONTROL MODULE
BRN WIRE
CHASSIS CONTROL MODULE
CONTROL SOLENOID VALVE ASSEMBLY
CONV/ TOP 1 FUSE
CONV/ TOP 2 FUSE
CONVERTIBLE W/ ENHANCED AUDIO
DK BLU WIRE
DLIS FUSE
ECM BATT FUSE
ENGINE CONTROL MODULE
EXH FLAP FUSE
EXHAUST FLOW CONTROL VALVE EXH RELAY FLAP FUSE
EXHAUST FLOW CONTROL VALVE RELAY
FOLDING TOP CONTROL MODULE
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 5)
FROM HVAC FUSE (DIAGRAM 3 OF 5)
FSCM FUSE
GARAGE DOOR OPENER
IGN
IGN IGN
IGNITION SWITCH
INSIDE GARAGE REARVIEW DOOR MIRROR OPENER
INSIDE REARVIEW MIRROR
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK (LEFT END OF DASH)
KEY-IN IGNITION SWITCH
M/T
M/T A/T CONV/ TOP 2 FUSE
OFF
PNK WIRE
PREMIUM AUDIO
RADIO
RADIO TELEMATIC VECHICLE LOCALIZATION, IMMOBI- LIZATION CONTROL MODULE
RDO FUSE
REAR PARKING ASSIST CONTROL MODULE
RED WIRE
RTD FUSE
RUN WIRE
RVC FUSE
SUBWOOFER SPEAKER
SUSPENSION CONTROL MODULE
SUSPENSION CONTROL SUBWOOFER MODULE SPEAKER
TELEMATIC VEHICLE LOCALIZATION, IMMOBI- LIZATION CONTROL MODULE
TO UNDERHOOD FUSE BLOCK (DIAGRAM 4 OF 5)
TRANS- MISSION CONTROL MODULE
UGDO/ URPA FUSE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> SUSPENSION CONTROL SUBWOOFER MODULE SPEAKER
