Chevrolet Camaro V facelift (2013-2015) right hdlp leveling mtr 3 Wiring diagram
This page shows the only wiring diagram for the component.right hdlp leveling mtr 3, which is found in the car Chevrolet Camaro V facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right hdlp leveling mtr 3 (1 of 1)
AFL/AHL BATT FUSE
BLK WIRE
BREAKOUT TO HEADLAMP LEVELING MODULE)
BREAKOUT TO LEFT HEADLAMP LEVELING ACTUATOR)
BRN/WHT WIRE
COMMUNICATION ENABLE
COMPUTER DATA LINES SYSTEM
GMLAN SERIAL DATA
GMLAN SERIAL DATA - GMLAN SERIAL DATA +
GRY WIRE
GRY/BLK WIRE
HEADLAMP LEVELING CONTROL MODULE
HEADLAMP LEVELING CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT)
HOT AT ALL TIMES
LEFT FRONT SUSPENSION POSITION SENSOR
LEFT FRONT SUSPENSION POSITION SENSOR (LEFT FRONT WHEELWELL)
LEFT HDLP LEVELING MTR 1
LEFT HDLP LEVELING MTR 2
LEFT HDLP LEVELING MTR 3
LEFT HDLP LEVELING MTR 4
LEFT HDLP LEVELING MTR RTN
LEFT HEADLAMP LEVELING ACTUATOR
LEFT HEADLAMP LEVELING ACTUATOR (REAR OF LEFT HEADLIGHT ASSEMBLY)
LEFT REAR SUSPENSION POSITION SENSOR
LEFT REAR SUSPENSION POSITION SENSOR (LEFT REAR WHEELWELL)
LO REF
LR STRUT SENS SIG
LR STRUT SENS VOLT REF
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PNK/BLK WIRE
PPL/WHT WIRE
RED/WHT WIRE
RF STRUT SENS SIG
RIGHT HDLP LEVELING MTR 1
RIGHT HDLP LEVELING MTR 1 RIGHT HDLP LEVELING MTR 3 RIGHT HDLP LEVELING MTR 4
RIGHT HDLP LEVELING MTR 2
RIGHT HDLP LEVELING MTR 2 GND
RIGHT HDLP LEVELING MTR 3
RIGHT HDLP LEVELING MTR 4
RIGHT HDLP LEVELING MTR RTN
RIGHT HEADLAMP LEVELING ACTUATOR
RIGHT HEADLAMP LEVELING ACTUATOR (REAR OF RIGHT HEADLIGHT ASSEMBLY)
SENS VOLT REF
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
YEL/BLK WIRE
Go to component -> Headlamps leveling circuit -> RIGHT HDLP LEVELING MTR 3
