Chevrolet Camaro V facelift (2013-2015) onstar phone switch switch Wiring diagram
This page shows the only wiring diagram for the component.onstar phone switch switch, which is found in the car Chevrolet Camaro V facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram onstar phone switch switch (1 of 1)
1 2 MIRROR DIMMING
14 12 PNK WIRE
9 8 PNK WIRE
BLK WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER OUTSIDE REARVIEW MIRROR GLASS
EMER- GENCY SWITCH
EMERGENCY IND
GRY WIRE
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
LOGIC
LT GRN WIRE
LT GRN/BLK WIRE
MIRROR DIMMING
ONSTAR IND
ONSTAR PHONE SWITCH SWITCH
PHONE IND
PNK WIRE
REAR BODY FUSE BLOCK (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RED/WHT WIRE
TELEMATICS BUTTON ASSEMBLY
UGDO/URPA FUSE
W/O GARAGE DOOR OPENER
WHT WIRE
Go to component -> Electrochromic mirror circuit, with light sensitive rearview mirror -> ONSTAR PHONE SWITCH SWITCH
