Chevrolet Camaro V facelift (2013-2015) data - data - data + data + ref gnd Wiring diagram
This page shows the only wiring diagram for the component.data - data - data + data + ref gnd, which is found in the car Chevrolet Camaro V facelift (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data - data - data + data + ref gnd (1 of 1)
1 2 BATT POS VOLT GROUND
ANTI-LOCK BRAKES SYSTEM
AUTOMATIC TRANSMISSION ASSEMBLY
BATT POS VOLT
BLK WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CONTROL SOLENOID VALVE ASSEMBLY AUTOMATIC TRANSMISSION ASSEMBLY
DATA
DATA - DATA - DATA + DATA + REF GND
DATA COMM ENABLE
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
ELECTRONIC BRAKE CONTROL MODULE
ELECTRONIC BRAKE CONTROL MODULE (ON RIGHT FRONT STRUT TOWER)
GROUND
HI SPD SERIAL DATA BUS + HI SPD SERIAL DATA BUS -
HI SPD SERIAL DATA BUS + HI SPD SERIAL DATA BUS - DATA COMM ENABLE
HI SPD SERIAL DATA BUS -
HOT AT ALL TIMES
HOT AT ALL TIMES POWER STEERING FUSE HOLDER (MOLDED INTO BATTERY POSITIVE CABLE)
LOGIC INSTRUMENT CLUSTER
LT BLU WIRE
ORG/BLK WIRE
POWER STEERING CONTROL MODULE (PART OF STEERING GEAR RACK ASSEMBLY)
POWER STEERING FUSE HOLDER
POWER STEERING MOTOR
POWER STEERING MOTOR (INTEGRAL TO STEERING GEAR)
POWER STEERING SHAFT TORQUE SENSOR
RED WIRE
REF
SPLY VOLT
STEERING WHEEL ANGLE SENSOR
STEERING WHEEL ANGLE SENSOR (TOP OF STEERING COLUMN)
SYSTEM
TAN WIRE
TAN/BLK WIRE
TRANS- MISSIONS SYSTEM
TRANSMISSION CONTROL MODULE
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
YEL WIRE
Go to component -> Electronic power steering circuit -> DATA - DATA - DATA + DATA + REF GND
