Chevrolet Camaro V facelift (2013-2015) convertible top curtain down sens sig Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 CONVERTIBLE TOP HEADER LATCH SW SIG B+ B- BLK WIRE BLK/YEL WIRE BRN WIRE CLOSE COMPUTER DATA LINES SYSTEM CONV/ TOP 1 FUSE CONV/ TOP 2 FUSE CONVERTIBLE TOP CLOSE SW SIG CONVERTIBLE TOP CURTAIN DOWN SENS SIG CONVERTIBLE TOP CURTAIN DOWN SENS SIG 14 15 16 PPL CONVERTIBLE TOP OPEN SW SIG CONVERTIBLE TOP HEADER LATCH SW SIG CONVERTIBLE TOP MTR DOWN CTRL CONVERTIBLE TOP MTR UP CTRL CONVERTIBLE TOP OPEN SW SIG CONVERTIBLE TOP POSITION SENS SIG CONVERTIBLE TOP POSITION SENS SPLY VOLT CONVERTIBLE TOP TRUNK STOWAGE SW SIG DK BLU WIRE DK GRN WIRE FOLDING TOP CONTROL MODULE (BEHIND CENTER REAR SEAT BACK) FOLDING TOP CONTROL SWITCH FOLDING TOP HEADER LATCH POSITION SWITCH FOLDING TOP HEADER LATCH POSITION SWITCH (RIGHT SIDE OF WINDSHIELD HEADER) FOLDING TOP LUGGAGE BARRIER SENSOR FOLDING TOP LUGGAGE BARRIER SENSOR (LEFT SIDE OF LUGGAGE COMPT) FOLDING TOP POSITION SENSOR FOLDING TOP POSITION SENSOR (IN REAR COMPT) FOLDING TOP PUMP MOTOR FOLDING TOP PUMP MOTOR (FRONT OF LUGGAGE COMPT) GRY WIRE HOT AT ALL TIMES LO REF LO SPD GMLAN SERIAL DATA NCA WIRE PPL REAR BODY FUSE BLOCK REAR BODY FUSE BLOCK (RIGHT SIDE OF LUGGAGE COMPT) RED WIRE RED/BLK WIRE RED/WHT WIRE TAN/BLK WIRE WHT WIRE YEL WIRE
