Chevrolet Camaro V facelift (2013-2015) cam w return low ref Wiring diagram

5 V REF 1 5 VIL REF BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CAM W RETURN LOW REF CAM X RETURN LOW REF CAM Y RETURN LOW REF CAM Z RETURN LOW REF CAMSHAFT EXHAUST SENS CAMSHAFT INTAKE SENS CAMSHAFT LOW REF (1) CAMSHAFT LOW REF (2) CAMSHAFT POSITION SENS CAMSHAFT POSITION SENSOR EXHAUST BANK 1 CAMSHAFT POSITION SENSOR EXHAUST BANK 1 (RIGHT FRONT OF RIGHT CYLINDER BANK) CAMSHAFT POSITION SENSOR EXHAUST BANK 2 CAMSHAFT POSITION SENSOR EXHAUST BANK 2 (LEFT FRONT OF LEFT CYLINDER BANK) CAMSHAFT POSITION SENSOR INTAKE BANK 1 CAMSHAFT POSITION SENSOR INTAKE BANK 1 (LEFT FRONT OF RIGHT CYLINDER BANK) CAMSHAFT POSITION SENSOR INTAKE BANK 2 CAMSHAFT POSITION SENSOR INTAKE BANK 2 (RIGHT FRONT OF LEFT CYLINDER BANK) CAMSHAFT SOLENOID (1) CAMSHAFT SOLENOID (2) COOLANT TEMPERATURE CRANKSHAFT POSITION SENSOR CRANKSHAFT POSITION SENSOR (LOWER LEFT FRONT OF ENGINE) DIRECT FUEL CYLINDER 1 DIRECT FUEL CYLINDER 2 DIRECT FUEL CYLINDER 3 DIRECT FUEL CYLINDER 3 DIRECT FUEL CYLINDER 6 DIRECT FUEL CYLINDER 1 SIG GND DIRECT FUEL CYLINDER 4 DIRECT FUEL CYLINDER 4 DIRECT FUEL CYLINDER 5 DIRECT FUEL CYLINDER 2 DIRECT FUEL CYLINDER 5 DIRECT FUEL CYLINDER 6 DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE CONTROL MODULE ENGINE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) ENGINE COOLANT SENS ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL PRESSURE SENSOR ENGINE OIL PRESSURE SENSOR (ON OIL FILTER HOUSING) FUEL RAIL PRESSURE SENSOR FUEL RAIL PRESSURE SENSOR (FRONT OF FUEL INJECTOR RAIL) GRY WIRE GRY/BLK WIRE HI FUEL PUMP ACTUATOR HI FUEL PUMP CTRL HIGH PRESSURE FUEL PUMP HIGH PRESSURE FUEL PUMP (TOP REAR OF LEFT CYLINDER BANK) IGNITION CONTROL (6) IGNITION CTRL (5) IGNITION CTRL 1 IGNITION CTRL 2 IGNITION CTRL 3 IGNITION CTRL 4 IGNITION CTRL LOW REF LOW REF LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/WHT WIRE M/T MANUAL TRANSMISSION FLUID TEMPERATURE SENSOR OIL PRESSURE SENS SIG ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PPL PPL 12 13 14 15 PPL PPL PPL/WHT WIRE SIG GND TAN WIRE TAN/WHT WIRE WHT TAN/ WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
