Chevrolet Camaro V facelift (2013-2015) 42 26 54 low ref sens sig 5 volt ref 2 Wiring diagrams

This page contains all the electrical diagrams for the component. 42 26 54 low ref sens sig 5 volt ref 2, in which he is found in the car Chevrolet Camaro V facelift (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram 42 26 54 low ref sens sig 5 volt ref 2 (1 of 4)

Wiring diagram 42 26 54 low ref sens sig 5 volt ref 2 for Chevrolet Camaro V facelift (2013-2015) (1 of 4)

Get access

2 3 1 (OR PNK) WIRE 23 24 7 13 DATA BUS - DATA BUS + SENSOR SIG 5 VOLT REF 2501 2500 COMPUTER DATA LINES SYSTEM 27 63 43 42 26 54 LO REF SEN SIG VOL REF 33 53 27 28 SERIAL DATA BUS - SERIAL DATA BUS + 42 26 54 LOW REF SENS SIG 5 VOLT REF 2 47 73 IGN GROUND 5 VOLT REF 5-VOLT REF 2 6.2L VIN 3, VIN W 6.2L VIN J/VIN W, 7.0L 6.2L VIN P M/T 71 72 VSS SIG HI VSS SIG LOW A/T A/T 6.2L VIN 3, VIN W ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY) APP SENS 2 SIG APP SENS 2 SIG LOW REF PPL AUTOMATIC TRANSMISSION ASSEMBLY BCM 6 FUSE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR BRAKE PEDAL POSITION SENSOR (MOUNTED ON BRAKE PEDAL BRACKET) BRN WIRE BRN/GRN WIRE CANCEL CRUISE SWITCH CLUTCH PEDAL POSITION SENSOR CLUTCH PEDAL POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL ASSEMBLY) COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY CRUISE CTRL SW SIG CRUISE IND CRUISE SWITCH DATA BUS - DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER DISPLAY ECM FUSE ENGINE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED HOT W/ IGNITION RUN RELAY ENERGIZED IGN IGN FUSE INSTRUMENT CLUSTER ISS SIG ISS/OSS SPLY VOLT LEFT STEERING WHEEL CONTROL SWITCH LO REF LOGIC LOW REF LT BLU WIRE LT BLU/WHT WIRE OSS SIG PNK WIRE PNK/BLK WIRE POSITIVE VOLTAGE PPL PPL/WHT WIRE RED WIRE RED/WHT WIRE RES+ RIGHT STEERING WHEEL CONTROLS SWITCH SEN SIG SENS SIG SENSOR SIG SER DATA SERIAL DATA BUS (+) SERIAL DATA BUS (-) SERIAL DATA BUS- SET- STEERING WHEEL AIR BAG COIL STEERING WHEEL AIR BAG COIL (UPPER STEERING COLUMN) SW REF VOLT SW SIG TAC MOTOR CTRL 1 TAC MOTOR CTRL 2 TAN WIRE TAN/BLK WIRE THROTTLE BODY (TOP FRONT OF ENGINE) TP SENS 1 SIG TP SENS 1 SIG LOW REF TP SENS 2 SIG TAC MOTOR CTRL 2 TAC MOTOR CTRL 1 TP SENS 2 SIG TRANSMISSION CONTROL MODULE TRANSMISSION INPUT SHAFT SPEED SENSOR TRANSMISSION OUTPUT SHAFT SPEED SENSOR UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VEHICLE SPEED SENSOR (M/T) (RIGHT REAR OF TRANSMISSION) VOL REF VSS SIG HI VSS SIG LOW WHT RED/ WIRE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

Go to component -> 6.2l vin j, cruise control circuit -> 42 26 54 LOW REF SENS SIG 5 VOLT REF 2
