Chevrolet Camaro V facelift (2013-2015) 25 24 gmlan serial data bus - gmlan serial data bus + Wiring diagram

25 24 GMLAN SERIAL DATA BUS - GMLAN SERIAL DATA BUS + 3.6L 6.2L VIN P 7.0L, 6.2L (VINW), 6.2L (VINJ) A/T BACKUP LAMP SWITCH BCM 6 FUSE BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE BODY CONTROL MODULE (LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY DK BLU WIRE ENGINE CONTROL MODULE ENGINE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) EXCEPT 3.6L 3.6L GMLAN SERIAL DATA BUS + GRN WIRE GRY WIRE HOT AT ALL TIMES INSIDE REARVIEW MIRROR LEFT BACKUP LAMP LEFT INNER TAIL/STOP, TURN SIGNAL LAMP LEFT OUTER TAIL/STOP, TURN SIGNAL LAMP LT GRN WIRE M/T NCA WIRE OF PACKAGE SHELF) (CONVERTIBLE: BEHIND RIGHT REAR QUARTERPANEL) ORG/BLK WIRE PARK/NEUTRAL SIG REARVIEW CAMERA REARVIEW CAMERA (CENTER OF REAR FASCIA) RED WIRE RED/WHT WIRE RIGHT BACKUP LAMP RIGHT INNER TAIL/STOP, TURN SIGNAL LAMP RIGHT OUTER TAIL/STOP, TURN SIGNAL LAMP SIG A SIG B SIG C SIG P SPLY VOLT SUPPLY VOLT SW SIG TAN WIRE TAN/BLK WIRE TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH AUTOMATIC TRANSMISSION ASSEMBLY TRANSMISSION INTERNAL MODE SWITCH AUTOMATIC TRANSMISSION ASSEMBLY (A/T) UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) W/ LIGHT SENSITIVE INSIDE REARVIEW MIRROR W/O LIGHT SENSITIVE INSIDE REARVIEW MIRROR WAKE UP SIG WHT RED/ WIRE WHT WIRE YEL WIRE
