Trunk release circuit for Chevrolet Camaro V (2009-2013)
Trunk release circuit
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
FUSE
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
LO SPD GMLAN SERIAL DATA
LO SPD GMLAN SERIAL DATA B+ 22 3
LOGIC
LOGIC BODY CONTROL MODULE (LEFT SIDE OF DASH)
LT BLU WIRE
PNK/BLK WIRE
REAR COMPARTMENT LID LATCH (CENTER REAR OF COMPARTMENT LID)
REAR COMPARTMENT LID RELEASE RELAY
REAR COMPARTMENT LID UNLATCH SWITCH)
REAR COMPT LID AJAR SW SIG
REAR COMPT LID RELEASE CTRL
REAR COMPT LID RELEASE SW
RED/WHT WIRE
TAN WIRE
TRUNK FUSE
