Car Wiring Diagrams for Starting circuit for Chevrolet Camaro V (2009-2013)

3.6L 6281 (OR 6110) AUTOMATIC TRANSMISSION ASSEMBLY (A/T) BATTERY BATTERY FUSE BLOCK (AT BATTERY) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) VOLTAGE IGNITION BRN WIRE BRN/WHT WIRE CLUTCH PEDAL POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL ASSEMBLY) CLUTCH PEDAL POSITION SENSOR SIG COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY ENGINE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) ENGINE CONTROLS SYSTEM FUSIBLE LINK 1 (12 GA- GENERATOR GRY WIRE HI SPEED GMLAN SERIAL DATA BUS - HI SPEED GMLAN SERIAL DATA BUS - 5-VOLT REF 5-VOLT REF 1 HIGH SPEED GMLAN SERIAL DATA (+) IGNITION SWITCH LOCK LOW REFERENCE ORG/ WIRE ORG/BLK WIRE PARK/NEUTRAL SIG PNK WIRE PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE REFERENCE 5-VOLT RUN WIRE STARTER FUSE STARTER MOTOR STARTER RELAY STARTER RELAY CONTROL TAN WIRE TAN/BLK WIRE TRANSMISSION CONTROL MODULE TRANSMISSION INTERNAL MODE SWITCH UNDERHOOD BATTERY CABLE JUNCTION BLOCK (LEFT REAR OF ENGINE COMPT) UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE YEL WIRE
