Driver power seat circuit for Chevrolet Camaro V (2009-2013)
Driver power seat circuit
ADJUSTER SWITCH
BLK WIRE
DK BLU WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/YEL WIRE
DOWN
DRIVER SEAT
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT FRONT VERTICAL MOTOR (UNDER DRIVER'S SEAT)
DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER'S SEAT)
DRIVER SEAT REAR VERTICAL MOTOR (UNDER DRIVER'S SEAT)
DRIVER SEAT RECLINE MOTOR (UNDER DRIVER'S SEAT)
DRVR SEAT CIRCUIT BREAKER
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LT BLU WIRE
LT GRN WIRE
RED/ WHT WIRE
RED/WHT WIRE
RWD
TAN WIRE
W/ 6 WAY POWER SEAT
W/O 6 WAY POWER SEAT
WHT RED/ WIRE
YEL WIRE
