Headlamps leveling circuit for Chevrolet Camaro V (2009-2013)
Headlamps leveling circuit
AFL/AHL BATT FUSE
BLK WIRE
BREAKOUT TO HEADLAMP LEVELING MODULE)
BREAKOUT TO LEFT HEADLAMP LEVELING ACTUATOR)
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FRONT SUSPENSION HEIGHT SENSOR (AT FRONT SHOCK MOUNT)
GMLAN SERIAL DATA - GMLAN SERIAL DATA +
GRY WIRE
GRY/BLK WIRE
HEADLAMP LEVELING CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT)
HOT AT ALL TIMES
LEFT HDLP LEVELING MTR 4
LEFT HEADLAMP LEVELING ACTUATOR (BEHIND RIGHT HEADLIGHT)
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/BLK WIRE
ORG/WHT WIRE
PNK/BLK WIRE
PPL/WHT WIRE
REAR SUSPENSION HEIGHT SENSOR (AT REAR SHOCK MOUNT)
RED/WHT WIRE
RIGHT HDLP LEVELING MTR 1 RIGHT HDLP LEVELING MTR 3 RIGHT HDLP LEVELING MTR 4
RIGHT HDLP LEVELING MTR 2 GND
RIGHT HEADLAMP LEVELING ACTUATOR (BEHIND LEFT HEADLIGHT)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
YEL/BLK WIRE
