Chevrolet Camaro V (2009-2013) serial data wake-up sig Wiring diagram
This page shows the only wiring diagram for the component.serial data wake-up sig, which is found in the car Chevrolet Camaro V (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial data wake-up sig (1 of 1)
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN WIRE
DATA LINK CONNECTOR (DLC) (LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
DLC FUSE
DRIVER WINDOW MOTOR (DRIVER'S DOOR)
DRIVER WINDOW SWITCH (CONVERTIBLE)
GRY WIRE
HI SPD GMLAN SERIAL DATA
HI SPD GMLAN SERIAL DATA + HI SPD GMLAN SERIAL DATA -
HI SPD GMLAN SERIAL DATA BUS +
HI SPD GMLAN SERIAL DATA BUS + LINEAR INTERCONNECT NETWORK 1
HI SPD GMLAN SERIAL DATA BUS- HI SPD GMLAN SERIAL DATA BUS+
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
IMMOBILIZER ANTENNA (STEERING COLUMN)
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
LEFT REAR WINDOW MOTOR
LINEAR INTERCONNECT NETWORK 1
LINEAR INTERCONNECT NETWORK 11
LINEAR INTERCONNECT NETWORK 3
LINEAR INTERCONNECT NETWORK 4
LO SPD GMLAN SERIAL DATA
LT BLU WIRE
MULTI-AXIS ACCELERATION SENSOR
PASSENGER WINDOW MOTOR (FRONT PASSENGER'S DOOR)
RED/WHT WIRE
RIGHT REAR WINDOW MOTOR
SERIAL DATA COMMUNICATION ENABLE
SERIAL DATA WAKE-UP SIG
STEERING WHEEL ANGLE SENSOR (STEERING COLUMN)
SUNROOF CONTROL MODULE (IF EQUIPPED)
TAN WIRE
TAN/BLK WIRE
W/ REAR EXPRESS UP/DOWN
W/O ELECTRIC SLIDING GLASS SUN ROOF
Go to component -> Computer data lines circuit (1 of 3) -> SERIAL DATA WAKE-UP SIG
