Chevrolet Camaro V (2009-2013) rear compartment lid release relay Wiring diagrams
This page contains all the electrical diagrams for the component. rear compartment lid release relay, in which he is found in the car Chevrolet Camaro V (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear compartment lid release relay (1 of 2)
AIR BAG CLSTR FUSE FUSE
AOS FUSE
AUXILIARY GAUGE MODULE
BAT FUSE
BCM 1 BCM 5 FUSE BCM 7 FUSE FUSE FUSE
BCM 2 FUSE
BCM 3 BCM 4 FUSE
BCM 8 FUSE
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BODY CONTROL MODULE
DATA LINK CONNECTOR
DISPLY FUSE
DLC FUSE
DRIVER PASSENGER SEAT SEAT ADJUSTER ADJUSTER SWITCH SWITCH
DRVR SEAT CIRCUIT BREAKER
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 5)
HEAD-UP DISPLAY (IF EQUIPPED)
HVAC CONTROL MODULE
HVAC FUSE
INFLATABLE INSTRUMENT RESTRAINT CLUSTER SENSING, DIAGNOSTIC MODULE
INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
MULTIMEDIA PLAYER INTERFACE MODULE (W/ RECEPTACLE USB)
ONSTAR FUSE
PASS SEAT CIRCUIT BREAKER
PASSENGER PRESENCE DETECTION MODULE
RADIO/ HVAC CONTROLS
REAR COMPARTMENT LID RELEASE RELAY
RED WIRE
TO DLIS FUSE (DIAGRAM 5 OF 5)
TO INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 4 OF 5)
TRUNK FUSE
W/ 6 WAY POWER SEAT
W/ MULTI- FUNCTION AUXILIARY GAUGE
W/O 6 WAY POWER SEAT
WHT WIRE
Go to component -> Power distribution circuit (3 of 5) -> REAR COMPARTMENT LID RELEASE RELAY
Wiring diagram rear compartment lid release relay (2 of 2)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER DISPLAY
FUSE
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH)
INSTRUMENT CLUSTER
LO SPD GMLAN SERIAL DATA
LO SPD GMLAN SERIAL DATA B+ 22 3
LOGIC
LOGIC BODY CONTROL MODULE (LEFT SIDE OF DASH)
LT BLU WIRE
PNK/BLK WIRE
REAR COMPARTMENT LID LATCH (CENTER REAR OF COMPARTMENT LID)
REAR COMPARTMENT LID RELEASE RELAY
REAR COMPARTMENT LID UNLATCH SWITCH)
REAR COMPT LID AJAR SW SIG
REAR COMPT LID RELEASE CTRL
REAR COMPT LID RELEASE SW
RED/WHT WIRE
TAN WIRE
TRUNK FUSE
Go to component -> Trunk release circuit -> REAR COMPARTMENT LID RELEASE RELAY
