Chevrolet Camaro V (2009-2013) (fog lamp harness, 21.5 cm from breakout w/ hid w/ front fog lamp, hid Wiring diagram
This page shows the only wiring diagram for the component.(fog lamp harness, 21.5 cm from breakout w/ hid w/ front fog lamp, hid, which is found in the car Chevrolet Camaro V (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (fog lamp harness, 21.5 cm from breakout w/ hid w/ front fog lamp, hid (1 of 1)
3.6L
A/C COMPRESSOR AUXILIARY BRAKE CLUTCH BOOSTER PUMP
BATTERY
BLK WIRE
BRAKE FLUID LEVEL SWITCH
COOLING FAN SPEED CONTROL RELAY
ELECTRONIC BRAKE CONTROL MODULE
EXCEPT 3.6L
HIGH HOOD NOTE AJAR HORN SWITCH
IGNITION COIL 1
IGNITION COIL 2
IGNITION IGNITION COIL 4 COIL 6
IGNITION IGNITION COIL 5 COIL 3
IGNITION IGNITION IGNITION IGNITION COIL 1 COIL 3 COIL 5 COIL 7
IGNITION IGNITION IGNITION IGNITION COIL 4 COIL 6 COIL 8 COIL 2
LEFT COOLING FAN MOTOR
LEFT FRONT PARK LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP
LEFT HEADLAMP BALLAST
LEFT HIGH BEAM SOLENOID ACTUATOR
LEFT PARK/TURN SIGNAL LAMP
LOW LEFT NOTE HEADLAMP HORN
NCA WIRE
REAR IGNITION DEFOGGER RELAY RELAY DIODE
RIGHT COOLING FAN DIODE
RIGHT FRONT PARK LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP
RIGHT HIGH BEAM RIGHT RIGHT SOLENOID HEADLAMP HEADLAMP ACTUATOR BALLAST
RIGHT PARK/TURN SIGNAL LAMP
RUN WIRE
W/ HID
W/ W/O FRONT FRONT FOG LAMP FOG LAMP, HID, HID
W/O FRONT FOG LAMP, HID
W/O HID
W/O W/ HID HID
WINDSHIELD WASHER PUMP
WINSHIELD WASHER PUMP RELAY
Go to component -> Ground distribution circuit (1 of 3) -> (FOG LAMP HARNESS, 21.5 CM FROM BREAKOUT W/ HID W/ FRONT FOG LAMP, HID
