Chevrolet Camaro V (2009-2013) 22 10 3 gmlan serial data ambient lt sens sig b+ Wiring diagram
This page shows the only wiring diagram for the component.22 10 3 gmlan serial data ambient lt sens sig b+, which is found in the car Chevrolet Camaro V (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 22 10 3 gmlan serial data ambient lt sens sig b+ (1 of 1)
1 2 DRL CONTROL DRL CONTROL
10 18 FOG LP RELAY CTRL HI BEAM RELAY CTRL
22 10 3 GMLAN SERIAL DATA AMBIENT LT SENS SIG B+
3 4 9 11 16 10 B+ B+ HEADLAMP SW SIG OFF/LOW CTRL HDLPS ON SIG PARK BRAKE SW SIG
4 11 17 REF VOLT HI BEAM SIG FLASH TO PASS SIG PPL
AMBIENT LIGHT SENSOR (CENTER OF DASH)
AUTO
BCM 5 BCM 3 BCM 2 (LEFT SIDE FUSE FUSE FUSE OF DASH)
BEAM SW
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL DOOR RECEIVER)
CRUISE CONTROL SYSTEM
DIMMER
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FOG LAMP FUSE
FOG LP RELAY CTRL
FRONT FOG
FRONT FOG LAMP RELAY
FTP SW
HEAD
HEAD- LAMP
HEADLAMP SWITCH
HI HI BEAM BEAM RT LT FUSE FUSE
HIGH BEAM IND FRONT FOG LAMP IND
HIGH BEAM RELAY
HOT AT ALL TIMES
INSTRUMENT PANEL FUSE BLOCK
LAMP SWITCH
LEFT FRONT FOG LAMP
LEFT HEADLAMP
LO SPD GMLAN
LOGIC INSTRUMENT CLUSTER
LT BLU WIRE
LT GRN/BLK WIRE
OFF
PARK
PARK BRAKE SWITCH (BASE OF PARK BRAKE HANDLE)
PPL
REAR FOG
RED/WHT WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP
SER DATA
SWITCH
TAN/WHT WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlamps circuit, without high intensity discharge -> 22 10 3 GMLAN SERIAL DATA AMBIENT LT SENS SIG B+
