Chevrolet Camaro V (2009-2013) 10 7 network 3 accent lp ctrl ppl Wiring diagram

1 3 BATT POS VOLT BATT POS VOLT 10 7 NETWORK 3 ACCENT LP CTRL PPL BATT POS VOLT BCM 1 FUSE BCM 6 FUSE BLK WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COURTESY LP CTRL COURTESY LP SW COURTESY LP SW SIG DK GRN WIRE DOME/READING LAMPS DRIVER DOOR ACCENT LAMP DRIVER DOOR LATCH (REAR OF DRIVER DOOR) DRIVER WINDOW MOTOR (DRIVER'S DOOR) GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (LEFT SIDE OF DASH) BCM 5 FUSE INTR LP DEFALT SW LF DOOR AJAR SW SIG NETWORK 3 ORG/BLK WIRE PASSENGER DOOR ACCENT LAMP PASSENGER DOOR LATCH (REAR OF PASSENGER DOOR) PASSENGER WINDOW MOTOR (FRONT PASSENGER'S DOOR) PNK/BLK WIRE PPL PPL INTR LP DEFEAT SW SIG REAR COMPARTMENT COURTESY LAMP REAR COMPARTMENT LID LATCH (CENTER REAR OF COMPT LID) RED/WHT WIRE RF DOOR AJAR SW SIG RR COMPT LID AJAR SW SIG RR COMPT LP CTRL TAN/WHT WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WHT WIRE
