Courtesy lamps circuit, coupe for Chevrolet Camaro IV facelift (1998-2002)
Courtesy lamps circuit, coupe
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER RIGHT SIDE OF DASH)
COURTESY/ READING LAMPS
DK BLU/WHT WIRE
DOME LAMP
GROUND POWER (BATTERY) COURTESY LAMPS POWER FEED
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH) COURTESY FUSE 8
I/P COMPARTMENT LAMP
I/P DIMMER SWITCH
INSIDE REARVIEW MIRROR
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SIDE DOOR LOCK
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT LID AJAR INDICATION SWITCH
RIGHT FRONT SIDE DOOR LOCK
WHT WIRE
