3.8l vin k, compressor circuit for Chevrolet Camaro IV facelift (1998-2002)
3.8l vin k, compressor circuit
A/C CLUTCH RLY
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH DIODE (ENGINE HARN, NEAR FUEL INJECTOR 2 BREAKOUT)
A/C COMPRESSOR CLUTCH RELAY
A/C REQUEST SIG
A/C SENSOR SIG
A/C-CRUISE FUSE
BLK WIRE
BRN WIRE
DEF HTR/DEF
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROLS SYSTEM
GRY WIRE
HOT IN RUN
HOT IN RUN, BULB TEST OR START
HTR BI-LV VENT
HVAC CONTROL ASSEMBLY
HVAC FUSE 6
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LT BLU/BLK WIRE
NCA WIRE
NORM
OFF MAX
PNK WIRE
POWERTRAIN CONTROL MODULE (IN ENGINE COMPT, BEHIND RIGHT STRUT TOWER)
RED/BLK WIRE
SENSOR GROUND
UNDERHOOD FUSE BLOCK (BOTTOM) (LEFT FRONT OF ENGINE COMPT)
