Chevrolet Camaro IV facelift (1998-2002) wipers isolation diode Wiring diagram
This page shows the only wiring diagram for the component.wipers isolation diode, which is found in the car Chevrolet Camaro IV facelift (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wipers isolation diode (1 of 1)
BLK WIRE
DK GRN WIRE
END OF SWEEP SWITCH
GRY WIRE
HIGH MIST
HIGH MIST LOW OFF 3 6 0 3 9 8 2 5 0
HOT IN ACCY, RUN
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LOW PULSE
LOW SPEED RELAY
MIST
NCA WIRE
OFF
OFF LOW 2 7 0 6 8 0 PULSE
OFF ON
PARK RELAY
PARK SWITCH
PNK WIRE
PPL
RED WIRE
WASHER SWITCH
WIND- SHIELD WASHER PUMP (FWRD OF RAD SUPPT)
WIND- SHIELD WIPER MOTOR
WIPER/ WASH FUSE 14
WIPER/ WASHER SWITCH
WIPERS ISOLATION DIODE
YEL WIRE
Go to component -> Wiper/washer circuit -> WIPERS ISOLATION DIODE
