Chevrolet Camaro IV facelift (1998-2002) windows ckt breaker Wiring diagram
This page shows the only wiring diagram for the component.windows ckt breaker, which is found in the car Chevrolet Camaro IV facelift (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windows ckt breaker (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DOWN
ECB
FOLDING TOP PUMP (LEFT SIDE REAR COMPARTMENT, BEHIND CARPETING)
FOLDING TOP RELAY (BEHIND RIGHT SIDE OF DASH)
FOLDING TOP SWITCH
GRY WIRE
HOT IN ACCY, RUN OR DURING RETAINED ACCESSORY POWER (RAP)
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
ILLUM- INATION LAMP
NCA WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION SWITCH (UNDER CONSOLE, NEAR SHIFT CONTROL LEVER)
PPL
TAN WIRE
W/ETA W/O ETA
WHT WIRE
WINDOWS CKT BREAKER
Go to component -> Power top/sunroof circuits -> WINDOWS CKT BREAKER
