Chevrolet Camaro IV facelift (1998-2002) stoplamp/tcc switch assembly wiring diagram
This page shows the only wiring diagram for the component.stoplamp/tcc switch assembly, which is found in the car Chevrolet Camaro IV facelift (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stoplamp/tcc switch assembly wiring diagram (1 of 1)
A/T SHIFT LOCK CONTROL ACTUATOR SOLENOID (IN CONSOLE,
BLK/WHT WIRE
BRAKE TRANSMISSION SHIFT INTERLOCK SWITCH
DK GRN/WHT WIRE
FORWARD OF SHIFT CONTROL LEVER)
HATCH RELEASE RELAY
HOT IN RUN, BULB TEST OR START GAUGES FUSE 9
I/P FUSE BLOCK
ISOLATION DIODE (BTSI) (1 AMP)
ORG/BLK WIRE
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
POWER TOPS
POWERTRAIN CONTROL MODULE (PCM)
STOPLAMP/TCC SWITCH ASSEMBLY
TAN/WHT WIRE
Go to component -> Shift interlock circuit -> STOPLAMP/TCC SWITCH ASSEMBLY
