Chevrolet Camaro IV facelift (1998-2002) rear wheel speed sensor Wiring diagrams

This page contains all the electrical diagrams for the component. rear wheel speed sensor, in which he is found in the car Chevrolet Camaro IV facelift (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rear wheel speed sensor (1 of 3)

Wiring diagram rear wheel speed sensor for Chevrolet Camaro IV facelift (1998-2002) (1 of 3)

Get access

1 2 GROUND PUMP MTR CTRL 1995 VFTC ABS BATT MINI FUSE ABS IGN MINI FUSE ABS INOP INDICATOR ASR IND (CHEVROLET) TCS OFF IND (PONTIAC) BLK WIRE BLK/ WHT WIRE BRAKE INDICATOR BRAKE PRESSURE MODULATOR VALVE BRN/WHT WIRE DEL TOR DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (TOP OF LEFT FRONT FRAME RAIL) ENGINE WIRING HARNESS JUNCTION BLOCK 1 ABS BATT 1 MAXI FUSE ENGINE WIRING HARNESS JUNCTION BLOCK 2 GAUGES FUSE 9 GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FRONT WHEEL SPEED SENSOR LF WHL SPD LF WHL SPD LR WHL SPD LR WHL SPD LO TRAC INDICATOR LT BLU WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK IGNITION DEL TORQUE WIRE PNK WIRE POWER DISTRIBUTION SYSTEM POWERTRAIN CONTROL MODULE (BEHIND RIGHT STRUT TOWER) PPL/WHT WIRE PUMP MOTOR REAR WHEEL SPEED SENSOR RED WIRE REQ TOR REQ TORQUE SIG RF WHL SPD RF WHL SPD STOP LP FD RIGHT FRONT WHEEL SPEED SENSOR SERIAL DATA SPLICE PACK STOP/HAZARD FUSE 1 STOPLAMP/ TCC SWITCH (ON BRAKE PEDAL BRACKET) TACH OUT TACH SIGNAL GROUND BATTERY BATTERY GROUND TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCS SWITCH TCS IND TRACTION CONTROL SWITCH WHT WIRE WHT/ BLK WIRE YEL WIRE

Go to component -> 3.8l vin k, anti-lock brake circuits, with traction control -> REAR WHEEL SPEED SENSOR

Wiring diagram rear wheel speed sensor (2 of 3)

Wiring diagram rear wheel speed sensor for Chevrolet Camaro IV facelift (1998-2002) (2 of 3)

Get access

1 2 GROUND PUMP MTR CTRL 1995 VFTC ABS BATT 1 MAXI FUSE ABS BATT MINI FUSE ABS IGN MINI FUSE ABS INOP IND BLK WIRE BRAKE PRESSURE MODULATOR VALVE BRAKE WARNING IND DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (TOP OF LEFT FRONT FRAME RAIL) ENGINE WIRING HARNESS JUNCTION BLOCK 1 ENGINE WIRING HARNESS JUNCTION BLOCK 2 GAUGES FUSE 9 GROUND BATTERY BATTERY GROUND GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FRONT WHEEL SPEED SENSOR LF WHL SPD LF WHL SPD REAR WHL SPD REAR WHL SPD LOW TRAC IND LT BLU WIRE NCA WIRE ORG/ WIRE PNK IGNITION WIRE PNK WIRE PUMP MOTOR REAR WHEEL SPEED SENSOR RED WIRE RF WHL SPD RF WHL SPD STOP LP FD RIGHT FRONT WHEEL SPEED SENSOR SERIAL DATA SPLICE PACK STOP/HAZARD FUSE 1 STOPLAMP/ TCC SWITCH TAN WIRE TAN/WHT WIRE WHT WIRE YEL WIRE

Go to component -> Anti-lock brake circuits, without traction control -> REAR WHEEL SPEED SENSOR
