Chevrolet Camaro IV facelift (1998-2002) mirror position switch Wiring diagram
This page shows the only wiring diagram for the component.mirror position switch, which is found in the car Chevrolet Camaro IV facelift (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror position switch (1 of 1)
BLK WIRE
BLU WIRE
BRN/WHT WIRE
DOWN UP
DRIVER OUTSIDE REARVIEW MIRROR
FRONT PASSENGER OUTSIDE REARVIEW MIRROR
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT LT
MIRROR POSITION SWITCH
MIRROR SELECT SWITCH
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PWR ACCY FUSE 7
RED WIRE
RED/WHT WIRE
RIGHT LEFT
RIGHT/LEFT MOTOR
RIGHT/LEFT MOTOR UP/DOWN MOTOR
UP/DOWN MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> MIRROR POSITION SWITCH
