Chevrolet Camaro IV facelift (1998-2002) left turn relay Wiring diagram
This page shows the only wiring diagram for the component.left turn relay, which is found in the car Chevrolet Camaro IV facelift (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left turn relay (1 of 1)
AL SENS AL SENS IGNITION PRK BRAKE
BLK WIRE
BRN WIRE
CIRCUIT BREAKER
DAYTIME RUNNING LAMPS AMBIENT LIGHT SENSOR (TOP OF DASH)
DAYTIME RUNNING LAMPS MODULE (MOUNTED BEHIND RADIO AND HVAC CONTROLS)
DK BLU WIRE
DK BLU/WHT WIRE
FOG LAMP RELAY (IN TOP UNDERHOOD FUSE BLOCK)
FOG LAMP SWITCH
FUSIBLE LINK Z
GAUGES FUSE 9
GRN WIRE
GROUND
GRY WIRE
HEAD- LAMP DIMMER SWITCH
HEADLAMP SWITCH
HEADLIGHT RELAY
HIGH BEAM INDICATOR
HL ON IN
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (BEHIND LEFT SIDE OF DASH)
IGNITION
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL CLUSTER
LEFT FRONT FOG LAMP RIGHT FRONT FOG LAMP
LEFT HIGH BEAM HEAD- LAMP
LEFT LOW BEAM HEAD- LAMP RIGHT LOW BEAM HEAD- LAMP RIGHT HIGH BEAM HEAD- LAMP
LEFT TURN RELAY
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT TURN IN
OFF PARK HEAD
ON INDICATOR
ON OFF
ORG/ WIRE
PARK BRAKE SWITCH
PARK LIGHT RELAY
PNK WIRE
PPL
PPL PPL
RED WIRE
RIGHT TURN RELAY
RLY CTRL
RT TURN IN
SW ILLUM
TAIL LPS FUSE 5
TAN WIRE
TAN/WHT WIRE
TURN B/U FUSE 2
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlight circuit -> LEFT TURN RELAY
