Chevrolet Camaro IV facelift (1998-2002) (eng harn, approx 15 cm from Wiring diagram
This page shows the only wiring diagram for the component.(eng harn, approx 15 cm from, which is found in the car Chevrolet Camaro IV facelift (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (eng harn, approx 15 cm from (1 of 1)
3.8L (VIN K)
5.7L (VIN G)
A/C CLUTCH DIODE HEATED OXYGEN SENSOR
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH A/C CLUTCH DIODE
ACCELERATOR, SERVO CONTROL MODULE (ASM)
BANK 1 SENSOR 1
BANK 1 SENSOR 2
BANK 2 SENSOR 1
BANK 2 SENSOR 1 BANK 1 SENSOR 2
BANK 2 SENSOR 2
BATTERY
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
BRAIDED
CAMARO
CLUTCH PEDAL POSITION SWITCH
CRUISE CONTROL MODULE
DATA LINK CONNECTOR (DLC)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ELECTRONIC IGNITION CONTROL MODULE (ICM)
ENGINE OIL LEVEL SWITCH
ENGINE OIL LEVEL SWITCH MASS AIRFLOW (MAF) SENSOR
FIREBIRD
FUEL PUMP RELAY
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
IGNITION CONTROL COILS/MODULE BANK 1
IGNITION CONTROL COILS/MODULE BANK 2
IGNITION RELAY HORN
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER DATA LINK CONNECTOR (DLC)
M/T A/T
MASS AIRFLOW (MAF) SENSOR
NCA WIRE
PARK/ NEUTRAL POSITION SWITCH
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP OPENING DOOR ASSEMBLY
RIGHT HEADLIGHT
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
SECOND GEAR
SWITCH (CHEVY
THROTTLE ACTUATOR CONTROL (TAC) MODULE
TRACTION CONTROL SWITCH
TRACTION CONTROL SWITCH (CHEVY
Go to component -> Ground distribution circuit (1 of 3) -> (ENG HARN, APPROX 15 CM FROM
