Courtesy lamps circuit, convertible for Chevrolet Camaro IV (1992-1998)
Courtesy lamps circuit, convertible
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (MOUNTED ON HVAC MODULE, ABOVE RIGHT I/P INSULATOR PANEL)
CONSOLE COMPARTMENT LAMP
DK BLU/WHT WIRE
GROUND POWER (BATTERY) COURTESY LAMPS POWER FEED
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES I/P FUSE BLOCK COURTESY FUSE 8
I/P COMPARTMENT LAMP
I/P DIMMER SWITCH
LEFT DOOR JAMB SWITCH
LEFT REAR COURTESY LAMP
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
REAR COMPARTMENT LAMP
REAR COMPARTMENT LID AJAR INDICATION SWITCH
REARVIEW MIRROR)
RIGHT DOOR JAMB SWITCH
RIGHT REAR COURTESY LAMP
WHT WIRE
