Chevrolet Camaro IV (1992-1998) right turn relay Wiring diagram
This page shows the only wiring diagram for the component.right turn relay, which is found in the car Chevrolet Camaro IV (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right turn relay (1 of 1)
AL SENS AL SENS IGNITION PRK BRAKE
AMBIENT LIGHT SENSOR (TOP OF I/P, MOUNTED ON DEFROST GRILL)
BLK WIRE
BRN WIRE
DAYTIME RUNNING LAMPS (DRL) MODULE (MOUNTED BEHIND RADIO, HVAC CONTROLS)
DK BLU WIRE
DK BLU/WHT WIRE
FOG LAMP RELAY (UNDER- HOOD ELTRL. CNTR.: LEFT FRONT OF ENGINE COMPT.)
FOG LAMP SWITCH SW ILLUM
FUSIBLE LINK Z
GAGES FUSE 9
GRN WIRE
GROUND
GRY WIRE
HEAD- LAMP DIMMER SWITCH
HEADLAMP SWITCH
HEADLIGHT RELAY
HL ON IN
HOT AT ALL TIMES
HOT IN
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
IGNITION
INSTRUMENT CLUSTER HI BEAM INDICATOR
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT FOG LAMP
LEFT LO BEAM HEAD- LAMP RIGHT LO BEAM HEAD- LAMP
LEFT TURN RELAY
LT (NOT USED)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT TURN IN
OFF PARK HEAD
ON INDICATOR
ON OFF
ORG/ WIRE
PARK BRAKE SWITCH (IN CONSOLE, ON PARK BRAKE)
PARK LIGHT RELAY
PNK WIRE
PPL
RED WIRE
RED/WHT WIRE
RIGHT FRONT FOG LAMP
RIGHT HI BEAM HEAD- LAMP LEFT HI BEAM HEAD- LAMP
RIGHT TURN RELAY
RLY CTRL
RT TURN IN
RUN WIRE
SW ILLUM
TAIL LTS FUSE 5
TAN/WHT WIRE
TURN B-U FUSE 2
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlight circuit, with drl -> RIGHT TURN RELAY
