Chevrolet Camaro IV (1992-1998) right front abs brake pressure valve solenoid Wiring diagrams

ABS ASR/TCS RELAY ABS BAT FUSE 6 ABS IGNITION FUSE 1 ABS INOP INDICATOR ABS MOTOR PACK ABS VALVE FUSE 5 BLK WIRE BLK/WHT WIRE BRAKE COMBO VALVE BRAKE IN BATT BRAKE INDICATOR BRAKE SWITCH ASSEMBLY (BRAKE PEDAL BRACKET) BRN WIRE DATA LINK CONNECTOR (RIGHT OF STEERING COLUMN) DK BLU WIRE DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF I/P) FUSIBLE LINK B GAGES FUSE 9 HOT AT ALL TIMES HOT IN HOT IN RUN, BULB TEST OR START HYDRAULIC MODULATOR ASSEMBLY (LEFT FRONT OF ENGINE COMPT) I/P FUSE BLOCK IGN LEFT FRONT SOLENOID RLY COIL CTRL INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM (BRAKE WARNING) LEFT FRONT ABS BRAKE PRESSURE VALVE SOLENOID LEFT FRONT MOTOR LEFT FRONT WHEEL SPEED SENSOR LOW TRACTION INDICATOR LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE PONTIAC SOLID STATE CHEVROLET PPL PPL 1282 1283 1633 PPL PPL REAR MOTOR REAR WHEEL SPEED SENSOR RED WIRE RIGHT FRONT ABS BRAKE PRESSURE VALVE SOLENOID RIGHT FRONT MOTOR RIGHT FRONT WHEEL SPEED SENSOR RUN WIRE SERIAL DATA STOP/HAZARD FUSE 1 TAN WIRE TAN/WHT WIRE UNDERHOOD ELECTRICAL CENTER WHT WIRE YEL WIRE

22 23 PNK WIRE A/T ABS MOTOR PACK ASR SWITCH BLK WIRE BLK/WHT WIRE BRAKE VALVE COMBO BRN WIRE BRN/WHT WIRE CHEVROLET DK BLU WIRE DK GRN WIRE GRY WIRE HOT IN RUN HYDRAULIC MODULATOR ASSEMBLY (LEFT FRONT OF ENGINE COMPT) I/P FUSE BLOCK LEFT FRONT ABS BRAKE PRESSURE VALVE SOLENOID LEFT FRONT WHEEL SPEED SENSOR LEFT REAR WHEEL SPEED SENSOR LT BLU WIRE M/T ORG/ WIRE PNK WIRE PONTIAC PONTIAC (A/T) PONTIAC (A/T) PONTIAC (M/T) PONTIAC (M/T) PPL PPL PPL 1 2 PPL/WHT WIRE REAR MOTOR LEFT FRONT MOTOR RED WIRE RIGHT FRONT ABS BRAKE PRESSURE VALVE SOLENOID RIGHT FRONT MOTOR RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR TAN WIRE TAN/WHT WIRE TRACTION CONTROL SWITCH (CHEVROLET) TRACTION CONTROL SWITCH (PONTIAC-A/T) TRACTION CONTROL SWITCH (PONTIAC-M/T) TRACTION SWITCH TURN B-U FUSE 2 WHT WIRE YEL WIRE
