Chevrolet Camaro IV (1992-1998) reverse lockout solenoid Wiring diagram

1-2 SHIFT SOLENOID 2-3 SHIFT SOLENOID 3-2 CTRL SOLENOID A/C CLUTCH CTRL A/C COMPRESSOR RELAY A/C EVAP TEMP SENS IN A/C EVAPORATOR TEMP SENSOR (MOUNTED IN EVAPORATOR CORE) A/C PRESS SENSOR IN A/C REFRIGERANT PRESSURE SENSOR (ABOVE RIGHT SHOCK TOWER) A/T AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE CANISTER PURGE CTRL DATA LINK CONNECTOR (RIGHT OF STEERING COLUMN) DISTRIBUTOR DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FUEL PUMP PRIME CONNECTOR (TOP REAR OF RIGHT SHOCK TOWER) FUEL PUMP RELAY (FORWARD OF LEFT KICK PANEL) FUEL PUMP/ LEVEL SENDER (IN FUEL FUSE BLOCK GAGES FUSE 9 GROUND GRY OR WHT WIRE GRY WIRE HEI COIL WIRE HOT IN RUN, BULB TEST OR START HOT IN RUN, BULB TEST OR START ENG SENSOR FUSE 10 IGN IGN CTRL IGNITION COIL (FRONT LEFT SIDE OF ENGINE) IGNITION COIL MODULE (FRONT LEFT SIDE OF ENGINE) COIL DRIVER IGNITION FUSE 11 INSTRU- MENT CLUSTER MALFUNCTION INDICATOR KNOCK SENSOR (BOTTOM RIGHT SIDE OF ENGINE BLOCK) KNOCK SENSOR IN LT BLU WIRE LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE M/T MIL CTRL ORG/ WIRE OUTPUT/FIELD SERV ENBL PCM BAT FUSE 3 PNK WIRE POWERTRAIN CONTROL MODULE POWERTRAIN CONTROL MODULE (REARWARD OF RIGHT FRONT SHOCK TOWER) PPL PRESSURE CONTROL SOLENOID PROBE (INSERTED IN EVAPORATOR) RED WIRE RED/BLK WIRE REV LOCKOUT SOL CTRL PPL REVERSE LOCKOUT SOLENOID SERIAL DATA SKIP SHIFT IND CTRL SKIP SHIFT INDICATOR SKIP SHIFT SOLENOID TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TANK) TCC PWM SOLENOID TCC SOLENOID TCC SWITCH TRANS FLUID TEMP SENSOR TRANS FLUID TEMP SIG TRANS PRESS CTRL LO PNK IGNITION WIRE TRANS TCC CTRL UNDER- HOOD ELECTRICAL CENTER WHT WIRE WHT/BLK WIRE YEL/BLK WIRE
