Chevrolet Camaro IV (1992-1998) rear compartment lid ajar indicator switch Wiring diagram

1995 VFTC A/T ACCY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (ABOVE RIGHT I/P INSULATOR PANEL) BRN WIRE BULB TEST CLUTCH PEDAL POSITION SWITCH (MOUNTED TO TOP OF CLUTCH PEDAL) DK BLU WIRE DK GRN WIRE EXTERIOR LIGHTS SYSTEM (PARK LAMP RELAY) GRY WIRE GRY/BLK WIRE HORN SYSTEM (HORN RELAY) HOT AT ALL TIMES I/P FUSE BLOCK IGNITION KEY IGNITION KEY LOCK CYLINDER IGNITION SWITCH INSTRUMENT CLUSTER LED CONTROL FUEL ENABLE SIGNAL LEFT DOOR JAMB SWITCH LOCK OFF LT BLU WIRE LT GRN WIRE M/T ORG/ WIRE ORG/BLK WIRE PARK LP RELAY CTRL START ENABLE RLY GROUND PONTIAC CHEVY POWERTRAIN CONTROL MODULE (LEFT REAR OF ENGINE COMPT, ABOVE BATTERY) PPL PPL/WHT WIRE PWR ACCY FUSE 7 REAR COMPARTMENT LID AJAR INDICATOR SWITCH RESISTOR PELLET RIGHT DOOR JAMB SWITCH RUN WIRE SECURITY INDICATOR SECURITY INDICATOR LED SERIAL DATA STARTER SOLENOID THEFT DETERRENT RELAY (LOWER RIGHT SIDE OF I/P) TRANSMISSION RANGE SWITCH (IN CONSOLE, AT BASE OF SHIFT CONTROL LEVER) VIN P VIN K WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
